Safety
2
3
Residual heat indicators
After using the hob, residual heat remains in the heating area. The
LED shows the code “H” which indictates that the zone is not safe to
touch
Auto shut down protection
During operation the hob will automatically shut off as detailed in
chart below
Installation
Selection of installation equipment
Drill holes on the work surface in accordance to the sizes shown below.
Be sure the thickness of the work surface is at least 30mm. Please select
heat-resistant work surface material to avoid larger deformation caused by
the heat radiation from the hotplate.
As shown in Figure (1)
Power level 1 2 3 4 5 6 7 8 9
Default working
time(hour)
8 8 8 4 4 4 2 2 2
