Caterham SEVEN 620 R User Manual

10
Controls
1. Air vent
2. Oil pressure gauge
3. Temperature gauge
4. Heater fan control switch
5. Fuel gauge
6. Oil temperature gauge (CSR 260
only, Clock on all other models)
7. Indicators
Side/Head lights
Main beam
Headlamp flasher
8. Tachometer
9. Speedometer
10. Immobilizer warning light
11. Windscreen wipers
Wiper speed control
12. Windscreen washer switch
13. Gear lever
14. Heated screen switch
15. Horn Push button
16. Starter push button
17. Handbrake
18. Rear fog light switch
19. Hazard warning light switch
20. Heater valve control
Figure 2: Dashboard layout for CSR with Integral dash
