Figure 22: IR Close Start
Note: The controller will only start when inside the IR zone.
10 Ton Press
IR Emitter
CRUSH ZONE
Safe Zone
Figure 23: IR Function Enable
Note: The controller only operates the machine when it is inside the IR zone.
IR START CONE
About
40 degrees
