File playback
error
Music file in TF card might
have been removed or deleted,
causing the playback error
Update music library
USB DAC
cannot be
recognized
The driver has not been
installed or setup properly; PC
music playback software has
not designated this device as
playback output.
Install appropriate USB Audio
driver and select N3 as system
output device as your music
playback software on your
computer
System Halt
hold power until the player
reboot itself or use a non-metal
pin to activate reset button
directly
13. Technical Specifications
Specification
Dimension
100*54*13(mm)
Net Weight
～100g
Recommended Headphone
Impedance Range
8～300Ω
Battery
Capacity
2500mAh 3.8V Lithium ion polymer
Duration
～12HRS
Charging time
～3HRS (with 1.5-2A Charger, not
provided)
Charging current
≤1500mA when charge with 2A Charger,
≤500mA when charge with computer USB
port
Line Out
Output Level
1.0V (@10kΩ)
Frequency Response
20Hz-20kHz (±0.2dB,Fs=192kHz)
5Hz-50kHz (±2dB, Fs=192kHz)
THD+N
0.03% (kHz,Fs=44.1kHz;
20Hz-20kHz, A-Weighted)
Dynamic Range
108dB (20Hz-20kHz, A-Weighted)
SNR
108dB (20Hz-20kHz, A-Weighted)
Phones Out
Power rating
130mW+130mW (@32Ω)
Frequency Response
20Hz-20kHz (±0.2dB, Fs=192kHz)
5Hz-50kHz (±2dB, Fs=192kHz)
THD+N
0.03% (1kHz, Fs=44.1kHz；
20Hz-20kHz,A-Weighted)
Dynamic Range
108dB (20Hz-20kHz,A-Weighted)
SNR
108dB (20Hz-20kHz,A-Weighted)
Output Impedance
≤1Ω
Coaxial Out
Rated Output Level
0.5Vp-p (@75Ω)
Rated Output
impedance
75Ω
USB DAC
USB Mode
Asynchronized USB Audio 2.0 Class
DSD
Up to DSD128 (Native or DoP)
PCM
Up to 192kHz/24Bit
