Technical manual 12/13/14VAC Power supply v1.3EN
2. Warnings
FOR YOUR SAFETY - This product must be installed and maintained by an en-
gineer who is both authorized and qualified to repair pool equipment by the juris-
diction in which this product is installed, whenever local requirements of this kind
are enacted.
Make sure that the product is connected to a 120 VAC or 240 VAC plug, protected
against short-circuits. Product must be installed in due accordance with the Elec-
tric Code (hereinafter "CEC" or C22.1) and/or any other local or national codes.
Risk of electric shock, fire, injury or death. Only connect to a circuit that is pro-
tected by a ground fault circuit interrupter (GFCI).
To prevent any risk of electric shock, fire or accident, the product must be main-
tained exclusively by a qualified engineer specializing in the maintenance of pools.
Keep this apparatus out of the reach of children and any people with a reduced
physical, sensory or mental capacity.
This product must be used strictly according to the instructions for use presented
in this document. The user assumes any risk of injuries to people or damage to
property caused as a result of using the product.
3. Technical features
• Maximum overcurrent protection - 15 A
• Use copper conductors exclusively
• Disconnect the power supply before opening the service cover.
• For indoor or outdoor use
• Electrical requirements: 120 V AC 60 Hz
Power supply voltage (input) 120V ~ AC 60Hz
Output voltage 12/13/14 VAC
Output power
PF10V200 : 75VA maximum
PF10V201 : 150VA maximum
Protection index IP-55
Overall dimensions 310 x 150 x 100mm (12,2 x 5,9 x 3,9po)
Installation Wall attachment (3 screws/pegs provided)
Weight
PF10V200 : 2,3 kg (5,07lbs)
PF10V201 : 3,0 kg (6,62lbs)
Integrated supplementary protection
Circuit breaker, in front of the power supply:
7A (PF10V200) / 13A (PF10V201)
