Technical manual 12/13/14VAC Power supply v1.3EN
4. Description
This power supply is designed to safely powering your pool lights. Maximal output power is, depending
model, 75VA (PF10V200), or 150VA (PF10V201).
5. Installation
5.1. Wall mounting
For reasons of safety and in accordance with local directives and NEC, the supply
box must be installed
• either more than 3.5 m (11,5 ft) away (or even further if so required by local
legislation) from the edge of the pool. This distance is measured taking into ac-
count any workaround of obstacles. If the supply box is installed behind a wall,
this therefore concerns the distance required to go round it and reach the box.
• or in an underground room in close proximity to the pool. In this case, the room
must be accessible by a trap door which requires the use of a tool to be opened.
Use the 3 supplied screws and pegs to securely fix the box on the wall, on a flat and stable portion.
ccei.ca
3
