ccei PF10V200 - Page 5

Technical manual 12/13/14VAC Power supply v1.3EN
Primary choice depend on 2 installation-dependant parameters:
• Effective power of you pool light(s) and
• Cable gauge and lenght
For a consumed power of 1/3 of your power supply rated power (25VA for PF10R200 or 50VA for
PF10R201) :
Lenght AWG18 AWG16 AWG14 AWG12 AWG10
10m (33ft) #1(12V) #1(12V) #1(12V) #1(12V) #1(12V)
25m (83ft) #2(13V) #2(13V) #1(12V) #1(12V) #1(12V)
50m (165ft) #3(14V) #3(14V) #2(13V) #1(12V) #1(12V)
75m (247ft) #3(14V) #2(13V) #1(12V)
100m (329ft) #3(14V) #2(13V)
125m (411ft) #3(14V) #2(13V)
150m (493ft) #3(14V)
For a consumed power of 2/3 of your power supply rated power (50VA for PF10R200 or 100VA
for PF10R201) :
Lenght AWG18 AWG16 AWG14 AWG12 AWG10
10m (33ft) #1(12V) #1(12V) #1(12V) #1(12V) #1(12V)
25m (83ft) #2(13V) #2(13V) #2(13V) #1(12V) #1(12V)
50m (165ft) #3(14V) #3(14V) #2(13V) #1(12V)
75m (247ft) #2(13V) #2(13V)
100m (329ft) #3(14V) #2(13V)
125m (411ft) #3(14V)
150m (493ft) #3(14V)
For a consumed power of 100% of your power supply rated power (75VA for PF10R200 or 150VA
for PF10R201) :
Lenght AWG18 AWG16 AWG14 AWG12 AWG10
10m (33ft) #2(13V) #2(13V) #1(12V) #1(12V) #1(12V)
25m (83ft) #3(14V) #2(13V) #2(13V) #2(13V) #1(12V)
50m (165ft) #3(14V) #2(13V) #2(13V)
75m (247ft) #3(14V) #2(13V)
100m (329ft) #3(14V) #3(14V)
125m (411ft) #3(14V)
150m (493ft) #3(14V)
