model no. 040-1196-2
ASSEMBLY
6
Aligntheholesonthecentrebracket(A)with
correspondingupperholesonthestingerbase(B).
Secureusinghexbolt(K),twoflatwashers(Q)
andanylonlocknut(N)intheindicatedhole.
Tightenusing15/16"(24mm)socketwrench
andadjustablewrench.
Q
N
Q
K
A
B
B
C
A
23
Insertthetetheredpin(23)intothealignedholeson
thecentrebracket(A)andstingerbase(B).Secure
usingthepinclip(C).
1
2
3
ASSEMBLING THE BIKE CARRIER
TOOLS REQUIRED (NOT INCLUDED)
• 1"(25mm)adjustablewrench
• 1/2"(13mm)socketwrench
• 15/16"(24mm)socketwrench
• 3/4"(19mm)socketwrench
• 3/16"(4.76mm)hexdrivescrewdriver
E
A
Placethecentremast(E)onthecentrebracket(A)
sothattheholesonthebaseofthecentremast
alignwiththebracket.
A
D
O
S
M
Securethetwowheeltrayloadbars(D)tothe
centrebracket(A)usingfourstepbolts(M),four
flatwashers(S)andfournylonlocknuts(O).Tighten
usinga1/2"(13mm)socketwrench.
6
Placethetwowheeltrayloadbars(D)onthecentre
bracket(A)sothattheboltholesonthewheeltrayload
barsalignwiththecentrebracketholes.
A
D
5
O
S
E
A
L
Securethecentremast(E)tothecentrebracket(A)
usingtwostepbolts(L),twoflatwashers(S),and
twonylonlocknuts(O).Tightenusinga1/2"(13mm)
socketwrench.
4
7
