CCM 040-1196-2 - Page 5

model no. 040-1196-2
F
D
G
G
F
Insertthetwowheeltrays(driverside)(F)and
thetwowheeltrays(passengerside)(G)onto
eachendofthewheeltrayloadbars(D).
7
Note: Thisbikecarriercanbefittedtovehiclesequippedwitha11/4"(3.2cm)or2"(5cm)
hitchreceiver.
•Followsteps9to11forfittingthebikecarriertoa2"(5cm)hitchreceiver.
•Followsteps12to15forfittingthebikecarriertoa11/4"(3.2cm)hitchreceiver.
21
Rotatethehandknob(21)clockwiseoneach
wheeltraytosecurethetraysinplace.
Note: Rotatecounter-clockwisetoloosenthe
wheeltraysforadjustment.
8
8
ASSEMBLY
9
I
J
H
Tightentheanti-swayhitchpin(H)usinga3/4"
(19mm)socketwrenchandsecureitusingthe
hitchpinlock(I).
Note:Usekey(J)toremovethelock.
11
Inserttheanti-swayhitchpin(H)intothe
alignedholesofthe2"(5cm)receiver
adaptorandhitchreceiverusingaspring
washer(P)andflatwasher(R).
10
H
P
R
STINGER INSTALLATION FOR 2" (5 cm) HITCH RECEIVER
B
7
99
Insertthe2"(5cm)receiveradaptor(7)ofthe
stingerbase(B)intothe 2"(5cm) hitchreceiverof
thevehicle.
9
ASSEMBLY
