FOLDING THE BIKE CARRIER
Liftthecentrebracket(A)oftherackintowards
thevehicle.Reinsertthepin(23)andsecureusing
thepinclip(C).
Ensurethatthebikecarrierisnotloaded
withbicycles.
Pullthepinclip(C)fromthepin(23)onthestinger
base(B),thenremovethepin.
23
25
26
B
C
A
23
C
B
A
23
OPERATION
NOTE: Thewheeltrayscanbefoldedupwhiletherackisnotinuseorforstorage.
14
Tiltthecentremastintothewheeltrays,following
steps19-21.
24
•Wipethebikecarrierwithadampclothandmilddetergentaftereveryuseandbeforestorage.
•Foldthewheeltraysforcompactstorageofthebikecarrier.
•Storethebikecarrierindoorsandinacool,dryplace.
CLEANING
STORAGE
CLEANING AND STORAGE
