CCM 040-1196-2 - Page 7

F
E
model no. 040-1196-2
12
WARNING:
Hold the centre mast firmly while pulling the quick-release handle so as to
prevent the user from being hit by the rack arm
.
Ensurethatthebikecarrierisnotloaded
withbicycles.
19
TILTING THE BIKE CARRIER
Securethebicyclewheelswiththeleftandright
wheeltraysusingthebuilt-inratchetingstraps.
Insertthelooseendofthestrapintothebuckle
untilsnug.
Pressthefaceofthebuckletoreleasethestrap.
18
Note:Thebikecarriercanbetiltedforeasyaccesstothereartrunk/hatchofthevehicleandtopreventdamagetothe
carrierorvehiclewhileopeningthetrunklidofthevehicle.
Tiltthecentremast(E)tothepassengerside
ofthevehicle.Thecentremastwilllockintoits
loweredposition.
Afterloading,pullthequick-releasehandleand
liftthecentremast(E)backtoitsuprightposition,
ensuringthequick-releasehandlehaslocked
intoplace.
21
22
OPERATION
CAUTION:
Make sure the centre mast (E) is tilted while opening the trunk lid of the vehicle.
13
Holdthecentremast(E)andpullupwardson
thequick-releasehandleatthebaseofthemast.
20
OPERATION
E
E
