6.4 Ethernet
Ethernet is a common network protocol for local
area network. The CCV IM30 has an Ethernet 10/100
Base-T port.
1
TX+
TX-
2
RX+
3
Signal PIN
NC
4
5
NC
RX-
6
7
NC
NC
8
6.5 MDB-Slave
Multidrop Bus (MDB) is a communication protocoll
commonly used in vending machines. The CCV IM30
has a MDB slave port that can communicate to a
vending machine controller as well as accept an input
voltage of 9V to 42V. MDB Master and MDB Slave
to provide two separated MDB connectors with two
sepa-rated communcation ports. MDB level 1,2 and 3
are supported.
1
VDC
GND
2
NC
3
Signal
PIN
RX-
6
NC
8
