CCV IM30 - EVA SDM Cut-out Installation

5
MASTER_TX
COM (D_GND)
6
MASTER_RX
4
6.6 MDB-Master / Executive
The Executive protocoll (also known as BDV 001
proto-col) is a communication protocoll used in
vendinging machines. The CCV IM30 has a custom 20
pin connector (Amphenol 69168) that functions as a
MDB master port as well an Executive port.
1
MDB_PWR_IN
GND
2
V_OUT (unswitched)
3
Signal
PIN
5
MDB_MASTER_RX
MDB_MASTER_TX
6
GND
4
7
GND
GND
8
EXE_MASTER_RX+
9
11
GND
GND
12
EXE_MASTER_TX+
10
13
DIGI_IN4_H
DIGI_OUT2_H
14
DIGI_IN4_L
15
17
MDB_WAKEUP
DIGI_OUT2_L
16
