CDA FW221 User Manual

Reversing the door
It is possible to reverse the door on this appliance, if required.
To do so, follow the steps below:
• Loosen the hinge fixing screws (1).
• Open the door.
• Lever off the corner caps (3) with a knife blade.
• Insert the hinge fixing screws (1) on the opposite side.
• Remove the door fixing screws (2) and relocate the hinges
according to figure 3.
• Locate the door on the hinge fixing screws (1) and tighten.
Do not turn the door upside down.
• Insert the corner caps (3) in the exposed holes.
2
fig. 3

CDA FW221 Specifications

General

Brand	CDA
Model	FW221
Category	Refrigerator
Language	English
