CDA FW871 - Installation and Ventilation

16
Installation And
Ventilation
This appliance must never be
installed close to heat sources, e.g.
heating elements, cookers or in damp
places.
• To ensure the appliance is level, you
should use the height adjustable feet
at the front of the appliance.
• The cooling system at the rear of the
appliance must not touch the rear
wall.
• The appliance must be installed
with adequate ventilation. Ensure
that there is clearance above the
appliance to
allow air to escape and that there
is space between the rear of the
appliance and the wall.
The diagram shows the ventilation
requirements for your appliance.
Failure to provide adequate ventilation
can lead to increased running costs and
premature failure and may invalidate
the warranty provided with the
appliance.
fig. 7
1778
814
45
25
57
837
544
540
1785-
1790
min. 30
560-570
550 min
= airflow
FW851
fig. 8
1773
1003
32
25
65
648
544
540
1785-
1790
min. 30
560-570
550 min
= airflow
FW871
