9
Control panel
A. Green Power Light
This light is illuminated when the power supply to the appliance is on.
B. Fridge Thermostat Dial
The fridge temperature is regulated by this dial.
The thermostat can be set between fully anticlockwise (least cold) and
fully clockwise (coldest).
We recommend initially setting the temperature control in mid range
for the first 24 hours then adjusting the temperature up or down from
this point as your personal preference.
C. Freezer Temperature Indicators
These lights are illuminated to show the current temperature in the
freezer.
The -32 indicator will illuminate when the super frost function is
switched on.
D. Red Temperature Warning Light
When the freezer is over temperature, this light will switch on. The
light will remain on until the freezer temperature is below 5˚C.
B C D
A
E F G H
fig. 3
