43
Fig. 56
Fig. 57
Ring opening
Regulation of air supply to oven and grill burners
Using a screwdriver, slacken the screw securing the air flow regulation collar (fig. 56
and 57) and rotate the collar clockwise or anti-clockwise to increase or reduce the
air aperture in accordance with gas type and the indications in the “
TABLE FOR
THE CHOICE OF THE INJECTORS
”.
Light the burner and check the flame.
