Instruction Manual | 19
2. Pull the inner glass panel from its seat (in the lower section of the
door). Remove the inner panel (fig. D).
3. Clean the panel with warm water with some cleaning agent added.
Carry out the same in reverse order to reassemble the inner
glass panel. Its smooth surface should be pointed upwards. In
order to correctly fit the top door strip, first put the left end of the
strip on the door and then press the right end in until you hear a
“click”. Then press the left end in until you hear a “click”.
Important! Risk of damage to glass panel mounting.
Do not lift the glass panels up but pull it out.
Removal of the internal glass panel
D
1
2
3
1
2
3
1
2
3
