CONGA 11090 SPIN REVOLUTION HOME&WASHCONGA 11090 SPIN REVOLUTION HOME&WASH
5352
ENGLISH ENGLISH
10. Tank emptying channelling system
11. Tank emptying channelling system
12. Access tray and robot support
Mixed tank. Fig. 3:
1. Dust tank
2. Tank opening
3. Upper dusk tank lid
4. High-eciency lter + primary lter + sponge lter
NOTE:
The graphics in this manual are schematic representations and may not exactly match the
appliance.
2. BEFORE USE
- This robot vacuum cleaner includes a package designed to protect it during transport. Take
the robot vacuum cleaner out of the box. Keep the original box and other elements in a safe
place, as this will help you prevent product damage when transporting it in the future. In
case the original packaging is disposed of, make sure all packaging materials are recycled
accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or not in good condition, immediately contact the ocial Cecotec Technical
Support Service.
Warnings
- Remove all objects around the robot vacuum cleaner such as clothing, papers, cables,
curtains, or other fragile objects which may block or slow down the operation of the robot
vacuum cleaner. Fig. 4
- If the room to be cleaned is near a balcony or stairs, a physical barrier should be placed to
prevent the robot vacuum cleaner from falling and getting damaged, thus ensuring safe
operation. Fig. 5
- Do not use the robot vacuum cleaner for liquids. Fig. 6
- Direct exposure to sunlight or heavy light contrasts may aect the correct operation of the
sensors. If this happens, the robot vacuum cleaner will cease operation. Move it to a new
location for it to start running again.
- Please note that the total height of the robot vacuum cleaner is 10 cm and the sensors
are at the bottom, so it is advisable to prevent access to all areas below 10 cm to avoid
damaging the laser.
1. PARTS AND COMPONENTS
Fig. 1.1:
1. Charging terminals
2. Infrared sensor
3. Laser
4. Top lid
5. Back Home
6. Indicator lights
7. Power button
8. Infrared sensor
9. Rotating mops
10. Drive wheels
11. Main brush lid
12. Main brush
13. Side brush
14. Omnidirectional wheel
15. Fall-detection sensors
16. Battery
Robot mop accessories. Fig. 1.2:
1. Mains cable
2. Side brush
3. Mop (x2)
4. Self-cleaning brush
5. High-eciency lter
6. Self-emptying base bag
7. Instruction manual
Self-cleansing base. Fig. 2:
1. Dust tank
2. Clean-water tank
3. LED indicator light
4. Washing base
5. Dust tank lid
6. Waste-water tank
7. Water duct
8. Mop washing system
9. Charging terminals
