Technical specications and accessories
Joint Cutter CF-22 E.800
1.0 Technical data and accessories
of the CEDIMA® joint cutter CF-22 E.800
1.1 Technical data
Drive motor
Max. output
Rotational speed
Tensioning
Fusing
Ignition device
Electric motor
7.5 kW
2900 min
-1
400 V / 50 Hz
16amperes
Star-delta switch
Protection class IP54
Saw blade receptacle
Support taps (Ø)
right and left
25.4 mm
Driver pin Ø 8.0mm
Max. saw blade mounting width 10.0mm
RPM cutting shaft 2240min
-1
Max. saw blade-Ø 800 mm
Max. cutting depth 320 mm
Cutting depth adjustment Manual/spindle (crank handle)
Feed Manual
Water supply Compressed water at GEKA connection
Dimensions
Length/width/height 1420 mm / 650mm / 1025 mm
Weight
Separable in:
Rocker with motor and cutting shaft
Chassis
Blade guard
126 kg
77 kg
33 kg
16 kg
Sound pressure level at the work place *
Sound pressure level *
L
PA
= 78 dB (A)
L
WA
= 94 dB (A)
* During cutting work, higher values can occur.
