Hardware Overview
At A Glance
This section highlights all the major features of Robox®.
1
2
8
3
6
7
12
13
4
10
11
9
5
14
1 Print Head 8 X Axis Belt
2 X Carriage 9 Tip Wipe Blade
3 X Axis Rails 10 Reel Hub Cover
4 Print Bed 11 Door Interlock Latch
5 Y Axis Rail 12 Enclosure Door
6 Z Axis Rail and Drive Screw 13 Internal Ambient Lighting
7 Z Carriage (Right) 14 Front Tray Cover
