Celestron advanced VX Series User Manual

10 I ENGLISH
Computerized Hand Control
You have received a newly upgraded NexStar+ hand control with your telescope. The hand control now features a USB
connector used for linking to a PC with control software, and to perform firmware updates. This is a drop-in replacement
for all existing telescopes that accept the NexStar+ Hand Control with RS-232 Connector.
Update hand control firmware over USB without external power or without connecting to the mount. To update the firmware,
simply plug a mini USB cable (not included) from your PC to the port on the bottom of the hand control, and run
Celestron Firmware Manager (CFM), available for free from the support section on Celestron.com.
1
8
9
3
11
10
11
12
13
2
4
5
6
15
14
7
4

Celestron advanced VX Series Specifications

General

Mount Type	German Equatorial
Payload Capacity	30 lbs (13.6 kg)
Tracking Rates	Sidereal, Solar, Lunar
Database	40, 000+ objects
Software	NexStar+ hand control
Tripod	2" Stainless Steel
Motor Drive	DC Servo motors
Tracking Modes	EQ North, EQ South
Alignment Procedures	2-Star Alignment, 1-Star Alignment, Solar System Alignment
Power Requirements	12V DC
Slew Speeds	up to 4°/second
GPS	Optional (SkySync GPS accessory)
Communication Ports	RS-232 port
