ENGLISH I 23
Kit # 12067
Optical Design Schmidt-Cassegrain
Diameter 11” (280mm)
Focal Length 2800mm f/10
Eyepiece 40mm (70x) - 1.25”
Finderscope 9x50
Star Diagonal 90° - 1.25”
Mount Advanced VX
Tripod 2” Stainless Steel
Counterweights 3x 12 lb
Tube Length 24” (61 cm)
Tube Weight 28 lb
Optical Tube Assemblies
Depending on the telescope kit you purchased, you may have received one of the following optical tubes. This section of the
manual will walk you through the setup of the basic types.
Kit # 22020 32054 32062 12031
Optical Design Refractor Newtonian Newtonian Edge HD
Diameter 6” (150mm) 6” (150mm) 8” (200mm) 8” (203mm)
Focal Length 1200mm f/8 750mm f/5 1000mm f/5 2032mm f/10
Eyepiece 20mm (60x) - 1.25” 20mm (38x) - 1.25” 20mm (50x) - 1.25” 40mm (51x) - 1.25”
Finderscope 9x50 6x30 9x50 9x50
Star Diagonal 90° - 1.25” - - 90° - 1.25”
Mount Advanced VX Advanced VX Advanced VX Advanced VX
Tripod 2” Stainless Steel 2” Stainless Steel 2” Stainless Steel 2” Stainless Steel
Counterweights 2x 12 lb 1x 12 lb 2x 12 lb 1x 12 lb
Tube Length 51” (128 cm) 27” (69 cm) 27” (69 cm) 17” (43 cm)
Tube Weight 19 lb 10 lb 14 lb 13 lb
Kit # 12025 12079 12026 12046
Optical Design Schmidt-Cassegrain Schmidt-Cassegrain Schmidt-Cassegrain Schmidt-Cassegrain
Diameter 5” (125mm) 6” (150mm) 8” (203mm) 9-1/4” (235mm)
Focal Length 1250mm f/10 1500mm f/10 2032mm f/10 2350mm f/10
Eyepiece 25mm (50x) - 1.25” 20mm (75x) - 1.25” 25mm (81x) - 1.25” 25mm (94x) - 1.25”
Finderscope 6x30 6x30 6x30 6x30
Star Diagonal 90° - 1.25” 90° - 1.25” 90° - 1.25” 90° - 1.25”
Mount Advanced VX Advanced VX Advanced VX Advanced VX
Tripod 2” Stainless Steel 2” Stainless Steel 2” Stainless Steel 2” Stainless Steel
Counterweights 1x 12 lb 1x 12 lb 1x 12 lb 2x 12 lb
Tube Length 13” (33 cm) 16” (40 cm) 17” (43 cm) 22” (56 cm)
Tube Weight 10 lb 10 lb 12 lb 21 lb
