Celestron ASTROMASTER LT 70 AZ User Manual

3
Use the phone clamp knob to open the phone holder so
that your phone fits inside. Tighten it to secure your phone
in place.
Turn on the phone and open your camera app. Make sure
the flash is turned off.
Loosen the knob on the bottom of the adapter that secures the
phone clamp to the eyepiece clamp. Slide the phone clamp
up and down and rotate it left and right until your camera is
looking down through the eyepiece of the telescope. Tighten
the knob on the bottom of the adapter to secure it in place.
Use the telescope’s focuser to adjust focus of your camera.
Snap the image using your app or use the Bluetooth remote
described in the next section.
Open the eyepiece clamp and place it around the body of the
eyepiece. Tighten the clamp until it’s secure.
1
3
2
4 5
USING THE
SMARTPHONE
ADAPTER
