7
1 Control Panel (see below) 7 Optical Tube
2 Focus Knob 8 Schmidt Corrector Lens
3 Star Diagonal 9 Hand Control
4 Eyepiece 10 Fork Arm
5 Finderscope 11 Carrying Handle
6 Finderscope Adjustment Screw 12 Tripod
CONTROL PANEL C Auxiliary Port 2
A PC Interface Port D 12v Output Jack
B Auxiliary Port 1 E Auto Guider Port
6
5
4
2
1
9
AB C DE
Figure 2 – The NexStar GPS
10
8
3
7
11
12
