cellarking CX - CKR 50 Outdoor Unit Component Identification

22/23
55908014-06
Electrics box assembly
CKR 50 OUTDOOR UNIT COMPONENT IDENTIFICATION
BACK PANEL ASSY HEAT EXCHANGER COIL BULK HEAD PANEL VALVE PANEL SERVICE VALVE 1/2" SERVICE VALVE 3/8” HP SWITCH COMPRESSOR BASE LP SWITCH MOTOR SUPPORT BRACKET FRONT PANEL FAN GUARD FAN MOTOR CONTACTOR 3 MINUTE TIMER FAN CAPACITOR COMPRESSOR CAPACITOR FAN SPEED CONTROLLER (FSC) TERMINAL BLOCK
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
