Cellink BIO X EMD - Installing and Uninstalling Printhead

14
04 Geng started
4.2 Installing, raising, lowering and uninstalling the printhead
1. To install the printhead in the BIO X, stabilize the boom of the printhead mount with one hand to avoid straining the motor. Align the
printhead above the desired printhead mount and push downward using your opposite hand (Figure 4).
Note: for more informaon on how to assemble the printhead, see Secon 4.3.
Figure 4: Inserng the EMD Pneumac Printhead into the BIO X system.
