04 Geng started
5. Insert the adapter tool into the printhead (Figure 7 A, D). Twist the tool counterclockwise while securing the printhead with your other hand
(Figure 7 B, E). Pull the tool out with the Luer lock aached (Figure 7 C, F).
Figure 7: Removing the
Luer lock adapter. (A, D)
Insert the removal tool
into the EMD printhead.
(B, E) Fit the Luer lock
and twist counterclock-
wise unl loose. (C, F)
Pull out and remove the
adapter.
A
B
C
D E F
