33
Appendix C: Dipswitch settings for E6 devices
Settings used with E6 PIR
Function Dipswitch setting
1 2 3 4
Learn 0 0 0 1
Trigger 1 0 0 1
Use the Learn function setting to learn the device into the panel. After successfully
reading in the device, the dipswitch must be set to the trigger function.
Note: To Learn the device in, press the learn button or use TX shunt on older PIR's
Settings used with E6 Door Guard
Function Dipswitch setting
1 2 3 4
Learn 1 0 0 1
Trigger in away mode 0 1 0 1
Silent in any mode 0 0 1 1
Use the Learn function setting to learn the device into the panel.
Trigger in away mode: Will cause an alarm condition if triggered while the panel is in
away mode.
Silent in any mode: Trigger notification via telemetry outputs and keypad only.
Note: To Learn the device in use the NC or NO input, DO NOT USE THE PANIC BUTTON!!
WHEN USING E6 DEVICES, NO TAMPER AND PANIC FUNCTIONS ARE
AVAILIBLE! IF THESE FUNCTIONS ARE REQUIRED, USE E12 / E45 DEVICES.
