- 4 -
PARTS LIST
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1
Main frame 1
20
Allen bolt
M8XL72
2
2
Round end cap 2 21 Pedal (L/R) 1/1
3
Handlebar foam grip 2 22 Crank(L/R) 1/1
4
Computer 1 23 Leveler end cap 2
5
Handlebar 1 24 Rear stabilizer 1
6
Front handlebar cover 1 25 Allen Bolt
M8XL90
2
7
Allen Bolt
M8X15
8 26 Arc washer
D8X2 XΦ25 XR39
2
8
Pulse sensor wire 2 27 Pop-pin knob
M16X1.5X32
1
9
Rear handlebar cover 1 28 Saddle post bushing 1
10
Tapping screw
ST4.2X18
1 29 Vertical saddle Post 1
11
Handlebar post 1 30 Knob Nut
M10
1
12
Extension sensor wire 1 31 Flat washer
D10
1
13
Mast shield 1 32 Square end cap 2
14
Lower sensor Wire 1 33 U-shaped slider 1
15
Flat washer
D8
4 34 Horizontal saddle Post 1
16
Roller end Cap 2 35 Saddle 1
17
Cross tapping screw
ST3.5X20
4 36 Spring washer
D8
8
18
Front stabilizer 1 37 Cross screw
M5X10
2
19
Arc washer
D8XΦ19X1.5XR30
2 38 Power adaptor 1
NOTE:
Most of the listed assembly hardware has been packaged separately, but some hardware
items have been preinstalled in the identified assembly parts. In these instances, simply
remove and reinstall the hardware as assembly is required.
Please reference the individual assembly steps and make note of all preinstalled hardware.
PREPARATION: Before assembling, make sure that you will have enough space around the
item; Use the present tooling for assembling; before assembling please check whether all
needed parts are available.
It is strongly recommended this machine to be assembled by two or more people to avoid
possible injury.
