Celsius PHOENIX - Parts List

- 4 -
PARTS LIST
Parts
No.
Description
Quantity
Parts
No.
Description
Quantity
1
Main frame
1
21 L/R
Crank
1pr.
2
Phillips screw M5x12
4
22 L/R
Pedal
1pr.
3
Extension sensor wire
1
23
Crank shaft cap
2
4
Pulse sensor wire
2
24
Flange nut M8x25
2
5
Phillips screw M5x50
1
25
T-shaped knob M8x65
1
6
Arc washer D5
1
26
Leveler end cap
2
7
Handlebar
1
27
Rear stabilizer
1
8
Flat washer D8
1
28
Carriage bolt M8x73
4
9
Spacer
1
29
Vertical seat post
1
10
Handlebar chunk cover
1
30
Pop-pin knob M16x1.5
1
11
Tension controller
1
31
Knob nut M10
1
12
Handlebar post
1
32
Flat washer D10
1
13
Arc washer d8.5x1.5xφ25xR30
8
33
Horizontal seat post
1
14
Allen bolt M8x15
4
34
Saddle
1
15
Tension control cable
1
35
Handlebar top end cap
2
16
Sensor wire
1
36
Foam grip
2
17
Meter
1
37
Front mast cover
1
18
Front end cap
2
38
U-Shaped slider
1
19
Acorn nut M8
4
39
Square end cap
2
20
Front stabilizer
1
40
Screw
4
NOTE:
Most of the listed assembly hardware has been packaged separately, but some hardware items
have been preinstalled in the identified assembly parts. In these instances, simply remove and
reinstall the hardware as assembly is required.
Please reference the individual assembly steps and make note of all preinstalled hardware.
