TSR-UL-0061-1.3
22
3. Attach the front of the terminal to the back casing and fix in places with the screws.
4. Attach the side panels to the terminal.
Note
If the terminal needs to be open after installation, the side panels can be removed by inserting
a 5 mm (0.2”) flat head screwdriver into the slot under the centre of the panel and sliding along
the length of the panel.
