CEM Systems emerald TS100 - AC2000 Network Topology

TSR-UL-0061-1.3
CHAPTER 1 : Introduction
6
1.2 Simplified AC2000 Network Topology
Figure 4 Basic illustration of a typical AC2000 network including emerald configurations
Important
The emerald terminal is only available as an ethernet device.
