Indirect measurement - determining a distance using 2 auxiliary measurements
e.g. when measuring heights that require the measurement of two or three measurements as following step:
Press this button once, the display shows.
Aim at the upper point (1) and trigger the measurement.
After the first measurement the value is adopted. Keep the instrument
as horizontal as possible.
. (See ”Figure G”).
The distance to be measured flashes in the symbol.
Press to measurement the distance result of the horizontal point (2).
The result of the function is displayed in the summary line.
Indirect Measurement
Figure G
1
2
Laser Distance Meter User Manual
13
