CEMB ER71 - 4. CONTROL PANEL; 1-2 Digital Readouts: Unbalance Amount; 3-4 Digital Readouts: Unbalance Position; 9 Push Button: Cycle Start

8
Ver. 05-2015
1 2
5
3 4
6
13
8
7
12
10
9
11
14
ENGLISH
Use and maintenance manual
Control panel
1-2 Digital readouts, AMOUNT OF UNBALANCE, inside/outside
3-4 Digital readouts, POSITION OF UNBALANCE, inside/outside
5 Push button, selection of mode of correction
6 Push button, unbalance below threshold
7 Push button, FUNCTIONS MENU
8 Push button, menu selection conrmation
9 Push button, cycle start
10 Push button, emergency/home
11 Position repeater push button
12 Push button, SPLIT (hidden weight)
13 Manual width setting buttons
14 Push button, gr/oz measuring unit selection
cAuTIoN
pRess The buTToNs WITh youR fINGeRs. NeveR use The couNTeRWeIGhT GRIppeRs oR oTheR poINTed objecTs!
WheN The beep sIGNAl Is eNAbled pRessING of ANy push buTToN Is AccompANIed by A “beep”.
4. Control panel
