Cembre B500 - General Characteristics

5
(1)
Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u
L
pA
= weighted continuous acoustic pressure level equivalent.
L
pCPeak
= maximum value of the weighted acoustic displacement pressure at the work place.
L
WA
= acoustic power level emitted by the machine.
(2)
Directive 2006/42/EC, annexe 1, point 2.2.1.1
Weighted root mean square in frequency of the acceleration the upper limbs are exposed to for each biodynamic
reference axis. Tests carried out in compliance with the indications contained in UNI ENV 25349 and UNI EN 28662
part 1st Standards, and under operating conditions much more severe than those normally found.
1. GENERAL CHARACTERISTICS
ENGLISH
B500 B500E B500T B500A
Application range suitable for installing electrical compression connectors on
conductors up to 300 mm
2
(600 MCM).
Rated crimping force
kN (US sh. ton) 63 (7.1)
Minimum crimping force
kN (US sh. ton) 60 (6.75)
Minimum operating pressure bar (psi) 661 (9587)
Dimensions (ref. to Fig. 7) mm (inches) 300 x 343 x 83 (11.8 x 13.5 x 3.3)
Weight with battery kg (lbs) 4,2 (9.2)
Motor V DC 18
Operating temperature °C (°F) -15 to +50 (+5 to +122)
Recommended oil AGIP ARNICA 32 or equivalents.
Operating speed twin speed operation and automatic switching from a rapid
advancing speed of the ram to a slower, more powerful
crimping speed.
Safety maximum pressure valve.
Rechargeable battery V / Ah / Wh 18 / 4.0 / 72
Type CB1840L (Li-Ion)
Weight kg (lbs) 0,66 (1.45)
Battery charger
ASC30-36
Input
type
EU
27044000
UK
27045000
AUS/NZ
27047000
USA/CAN
27046000
V / Hz 220 - 240 / 50 - 60 115 / 60
W 85
Acoustic noise
(1)
L
pA
dB (A) 73
L
pCPeak
dB (C) 94.5
L
WA
dB (A) 79
Vibration
(2)
m/s
2
0.575 max.
