ENGLISH
THE TOOL IS UNSUITABLE FOR CONTINUOUS USE AND SHOULD BE ALLOWED TO
COOL DOWN FOLLOWING UNINTERRUPTED, SUCCESSIVE CRIMPING OPERATIONS; FOR
INSTANCE, HAVING EXHAUSTED A FULLY CHARGED BATTERY IN ONE SESSION, DELAY
BATTERY REPLACEMENT FOR A FEW MINUTES.
O
BSERVE RECOMMENDED REST PERIODS ALSO WHEN USING AN EXTERNAL POWER
SUPPLY.
PROTECT THE TOOL FROM RAIN AND MOISTURE. WATER WILL DAMAGE THE TOOL
AND BATTERY. ELECTRO-HYDRAULIC TOOLS SHOULD NOT BE OPERATED IN POU-
RING RAIN OR UNDER WATER.
3.1) Using the battery charger
– Carefully follow the instructions in the battery charger manual.
3.2) General information on how to use batteries
In order to use the batteries correctly, please follow these rules:
– Use the battery until the automatic residual energy display still has 1-2 LEDs showing:
this means the battery is almost completely discharged and no loss in the life of the battery
has been caused.
– Be particularly careful when charging a new battery the fi rst 2-3 times in order to be certain
of maximising the available energy level.
– Allow the battery to cool down to ambient temperature prior to recharging.
– Rest the battery charger for at least 15 minutes between charges.
4. MAINTENANCE
The tool is robust, completely sealed and requires very little daily maintenance.
Compliance with the following points should help to maintain the optimum performance
of the tool:
4.1) Thorough cleaning
– Dust, sand and dirt are a danger for any hydraulic device.
Every day, after use, the tool must be wiped with a
clean cloth taking care to remove any residue,
especially close to pivots and moveable parts.
4.2) Storage (Ref. to Fig. 3)
– When not in use, the tool should be stored and
transported in the plastic case, to prevent damage.
The case is suitable for storing the tool and the
accessories.
Plastic case: VAL P9, size 543x412x130 mm
(21.4x16.2x5.1 inches), weighs 2,2 kg (4.8 lbs.).
