Page 6 For technical questions, please call 1-888-866-5797. Item 62813
Connection
A SPARK NEAR BATTERY MAY CAUSE BATTERY EXPLOSION.
TO REDUCE RISK OF A SPARK NEAR BATTERY follow these instructions
exactly.
TO PREVENT SERIOUS INJURY:
Wear ANSI-approved splash-resistant safety goggles and heavy-duty rubber
work gloves whenever connecting, disconnecting, or working near battery.
Battery acid can cause permanent blindness.
1. Place Float Charger within 3 feet of battery.
Disconnect the Quick-Connectors
from each other.
2. Select the proper Connector.
3. To permanently attach the Ring
Terminal Connector to the battery:
a. Bolt POSITIVE (RED) Ring Terminal
Connector to POSITIVE (POS, P, +)
post of battery.
b. Bolt NEGATIVE (BLACK)
Ring Terminal Connector to
NEGATIVE (NEG, N, –) post of battery.
4. To temporarily attach the Clip
Connector to the battery,
a. Connect POSITIVE (RED)
Clip Connector to POSITIVE
(POS, P, +) post of battery.
b. Connect NEGATIVE (BLACK)
Clip Connector to NEGATIVE
(NEG, N, –) post of battery.
WARNING! TO PREVENT SHORT
CIRCUIT AND FIRE: Do not leave
Clips attached indefinitely.
WARNING! Do not connect
Connector to carburetor, fuel lines,
or sheet-metal body parts.
Note: The LED will not light while
cables are disconnected.
5. Join the Connector’s Quick-
Connector plug with AC Adapter.
6. If cables are connected improperly,
disconnect the Quick-Connector plugs,
correct the battery connections, and
re-connect the Quick-Connector plugs.
LED Functions
1. Flashing Red: The Battery is connected
improperly or not functioning at all.
2. Solid Red: The Battery is charging.
3. Flashing Green: The Battery is
nearly completely charged.
4. Solid Green: The Battery is completely
charged, and the Maintainer is
monitoring the charged Battery.
After Use
1. Separate the Quick-Connector plugs
and cap them with the attached caps.
2. Unplug the AC Adapter.
3. Depending on the Connector in use, either:
• Stow Ring Terminal Connector
safely next to battery. Keep
clear of belts, blades, and any
other moving engine parts.
• Remove Clip Connector from battery.
4. Wipe the Charger with a clean, dry cloth
and store indoors out of reach of children.
