Page 11For technical questions, please call 1-888-866-5797.Item 63423
SAFETYOPERATIONMAINTENANCE ASSEMBLY
Charging Battery Outside Vehicle
A SPARK NEAR BATTERY MAY CAUSE BATTERY EXPLOSION.
TO REDUCE RISK OF A SPARK NEAR BATTERY FOLLOW THESE INSTRUCTIONS EXACTLY.
DO NOT PLUG IN CHARGER/STARTER UNTIL DIRECTED TO DO SO.
TO PREVENT SERIOUS INJURY:
Wear ANSI-approved splash-resistant safety goggles and heavy-duty rubber work gloves
whenever connecting, disconnecting, or working near battery.
Battery acid can cause permanent blindness.
WARNING! TO PREVENT SERIOUS
INJURY: Do not use Start setting to charge
batteries. Use to jump start only.
COLD BATTERIES: Begin charging at lowest rate,
increase rate as battery reaches normal temperature.
DO NOT CHARGE A FROZEN BATTERY.
1. Unplug Charger/Starter.
2. Attach at least a 24-inch-long
6-gauge (AWG) insulated battery cable to
NEGATIVE (NEG, N, –) battery post.
3. Connect POSITIVE (RED) charger clip to
POSITIVE (POS, P, +) post of battery.
CAUTION! Do not face battery when
making final connection.
4. Position yourself and free end of battery
cable as far away from battery as possible –
then connect NEGATIVE (BLACK) charger
clip to free end of battery cable.
5. Plug Charger/Starter into grounded 120V receptacle.
6. Turn Power Switch on.
7. Press Function Select Button until desired function
lights up. Refer to Table B on page 9.
WARNING! TO PREVENT SERIOUS INJURY: Do
not use 12V 200A Start function for charging.
8. Press Start/Stop button to start function.
9. When finished, turn Power Switch
off and unplug power cord.
10. When disconnecting Charger/Starter, always
do so in reverse sequence of connecting
procedure and break first connection while
as far away from battery as practical.
11. After use clean, then store the Charger/
Starter indoors out of children’s reach.
To Next Page
