CEN-TECH ITEM 98674 - Fuse Replacement Guide; Test Lead Replacement Guide

DIGITAL MULTIMETER
MAINTENANCE
5.2.4 Put the battery cover back and fix it again to its
original form.
WARNING
To avoid electric shock, make sure that the test leads
have been clearly move away from the circuit under
measurement before opening the battery cover of the
meter.
For protection against fire hazard, replace fuses with
specified ratings only: F 10A/250V (quick acting).
-
+
+
-
-
+
A
A
A
A
A
A
- 46 -
DIGITAL MULTIMETER
MAINTENANCE
5.3 REPLACING TEST LEADS
WARNING
The replacement must be test leads in good
working condition with the same or equivalent
rating: 1000V 10A.
A test lead must be replaced if the insulation layer has been
damaged, e.g. the wire inside is exposed.
- 47 -
