CEN-TECH ITEM 98674 - Page 9

DIGITAL MULTIMETER
SPECIFICATION
NTS
3.2.2 AC Voltage
Range
Resolution
Accuracy
400mV 0.1mV
4V 1mV ± (0.8% of reading + 3 digits)
40V 10mV
400V 100mV
750V 1V ± (1.0% of reading + 3 digits)
- Input Impedance: 10MΩ
- Overload protection:
400mV range: 250V DC or rms AC,
4V-750V ranges: 1000V DC or rms 750V AC.
- Max. input voltage: 1000V DC or rms 750V AC
- Frequency range: 40 to 400Hz
- Response: average, calibrated in rms of sine wave
NOTE:
At small voltage range, unsteady readings will appear before
the test leads contact the circuit. This is normal because
the meter is highly sensitive. When the test leads contact
the circuit, the true reading will be shown.
- 14 -
DIGITAL MULTIMETER
SPECIFICATION
NTS
3.2.3 DC Current
Range Resolution
Accuracy
400µA 0.1µA
4000µA
1µA
40mA 10µA ± （ 1.2% of reading + 3 digits ）
400mA
100µA
4A 1mA
10A 10mA ± （ 2.0% of reading + 10 digits ）
- Overload protection:
µA 、 mA ranges: resettable fuses F1 500mA/250V
10A range: F2 10A/250V fuse (quick acting).
- Max. input current:
mA jack （ µA ranges ） : 4mA,
mA jack （ mA ranges ） : 400mA,
10A jack: 10A
- voltage drop ：
400µA ranges: 40mV,
4000µA ranges: 400mV,
40mA ranges: 40mV,
400mA ranges: 400mV,
4A range: 40mV
10A range: 100Mv
- 15 -
