II. Specification
Gene ral Spe c ification:
Digital Display:
4 digits LCD display with maximum reading 9999
Over Load:
When the signal input exceeds the maximum limit “OL” will be display.
Sample Rate:
2 times/sec
Low Power Indication:
When the battery is below the proper operation range, symbol
will appear on the LCD display.
Auto Power Off:
The meter will power it self OFF after 10 minutes of inactivity.
Power Source: UM-4 or AAA 1.5V battery x 2.
Battery Life:
45 hr approx. (alkaline battery)
Backlight: LED with 180 sec auto shut down
Clamp opening size: 28mm
Dimension (L x W x H) :
218x64x30mm,
Weight: approx 280g( include battery)
Accessory:
Instruction Manual, Carrying Case, Test lead, Battery 1.5Vx2
