Center 260 - DCV Measurement; Continuity Measurement

Clamp Meter
9
6-4 DCV Measurement：
Switch the main function selector
to
range.
Connect red test lead to “+ ＂
terminal and black one to the
“COM＂terminal.
Measure the voltage by touch the
test lead tips to the test circuit
where the value of voltage is
needed.
Read the result from the LCD
panel.
6-5 Continuity Test With Buzzer：
Switch the main function to
range.
Connect red test lead to “ + ＂ terminal and black one to the
“COM＂terminal.
Connect tip of the test leads to the points where the conduction
condition needed.
If the resistance is under 120Ω, the beeper will sound continuously.
Short circuit Open circuit
