FIRESTAR COMBUSTION CONTROLLER - VERSION 6.7 • OPERATION MANUAL
Burn Time Monitor
Accumulated Fan Time Since Last Loading
Status
Fan Primary Secondary Connected
Power
IGNITION
AIR
e controller monitors how long the fan has been activated during the current
wood load. To view the accumulated fan time for this load, press and hold the
and button at the same time. is monitor will reset to 00:00 each time
the furnace is loaded with wood (i.e., the rebox door is left open for more
than 30 seconds). To manually reset this monitor, press the Ignition Air
button.
Easy Rere Burn Time Limit (Optional Feature)
is optional time-based feature can be enabled and operator-adjusted to “shut
the furnace down early” in an eort to preserve a portion of the current wood
load until the next loading. When appropriate, the word REFIRE may be
displayed on the LED display in relation to this mode.
