UNPACKING
When unpacking your Pick Up Truck Lift, check to make sure the following parts are included. If
any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this
manual.
Item # Description Qty Item # Description Qty
1 Base 1 17 Bolt 1
2 Post 1 18 Medium Pin 1
3 Grease Fitting 1 19 Small Pin 1
4 Boom 1 20 Large Lock Pin 1
5 Large Pin 1 21 Jack Handle 1
6 Cotter Pin 3 22 Bolt 5
7 Extendible Boom 1 23 Washer 5
8 Small Lock Pin 1 24 Lock Washer 5
12 Pump Unit * 1 25 Nut 5
13 Pump Release Valve 1 26 Steel Angle 2
14 Jack Support 1 27 Hook and Chain 1
15 Washer 1 28 Bolt 1
16 Spring Washer 1 29 Nut 1
* Includes parts #13-17.
GENERAL
Your Pick Up Truck Lift has four extension settings for the EXTENDIBLE BOOM (#7). Each of
these extension settings has a weight limit that is clearly marked on the BOOM (#4). Do not
exceed these weight limits as it may cause damage to the PICK UP TRUCK LIFT and\or cause
bodily harm.
Prior to use, liberally grease the unit using the GREASE FITTING (#3) located on the BASE (#1).
Swivel the BASE on the POST (#2) 360º while greasing to ensure optimum lubrication.
Warning: When installing the Pick Up Truck Lift, please note that
the Base (#1) must be securely bolted to the frame of the truck;
bolting the truck lift to the bed of the truck wil not provide the
necessary support needed.
Pg. 3 -- SKU 1647 REV 05/01
