Page 16 For technical questions, please call 1-888-866-5797. Item 60567
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Bolt M6x55 4
2 Spring Washer M6 4
3 Cylinder Head 1
4 Exhaust Elbow 1
5 Head Gasket 1
6 Valve Plate 2
7 Valve Reed 2
8 Valve Plate Gasket 1
9 Cylinder Upper Gasket 1
10 Cylinder 1
11 Cylinder Lower Gasket 1
12 Cap Screw M8x25 2
13 Spring Washer M8 2
14 Compression Ring 2
15 Oil Ring 1
16 Piston 1
17 Piston Pin 1
18 Retaining Ring Ø12 2
19 Connecting Rod 1
20 Crank 1
21 Cap Screw M8x22-LH 1
22 Bolt M6x18 4
23 Oil Sight Gauge 1
24 Oil Sight Gauge Seal 1
25 Crankcase Cover 1
26 Crankcase Cover Seal 1
27 Crankcase 1
28 Reset Button 1
29 Capacitor 1
30 Washer M8 1
31 Nut M8 5
32 Screw M3x6 2
33 Spring Washer M3 2
34 Fan 1
35 Retaining Ring Ø14 1
36 Screw M4x6 1
Part Description Qty
37 Ground Point Label 1
38 Washer M4 1
39 Capacitor Bracket 1
40 Rubber Ring 2
41 Shroud 1
42 Screw ST4.2x12 2
43 Washer M5 2
44 Bolt M6x18 4
45 Oil Fill Cap 1
46 Quick Coupler 1
47 Pressure Gauge Y40 1
48 Pressure Gauge Y50 1
49 Regulator 1
50 Connector, NPT 1/4" X 30 1
51 Pressure Switch 1
52 Plug, NPT 1/4" 1
53 Power Cord 1
54 Terminal U 2
55 Terminal O 1
56 Safety Valve 1
57 Drain Valve 1
58 Check Valve 1
59 Tank 1
60 Handle Grip 1
61 Relief Tube 1
62 Relief Nut 1
63 Exhaust Tube 1
64 Compression Nut 2
65 Washer Ø10 2
66 Rubber Foot 4
67 Washer M5 4
68 Screw ST 5x18 4
69 Bolt M8x55 4
70 Washer M8 4
71 Spring Washer M8 4
72 Air Filter 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Parts List and Diagram
Parts List
