Page 14 For technical questions, please call 1-800-444-3353. Item 60754
SAFETY MAINTENANCE PARTS LISTSETUP
Part Description Qty
1 Bolt 4
2 Spring Washer 4
3 Cylinder Head 1
4 Air Outlet 1
5 Discharge pipe 1
6 Air Filter Front Cover 1
7 Air Filter Rear Cover 1
8 Valve Plate 1
9 Valve Plate 1
10 Valve Seat 1
11 Cylinder Gasket 1
12 Bolt 4
13 Cylinder 1
14 Piston 1
15 Connecting Rod 1
16 Oil Fill Plug 1
17 Compression Ring 1
18 Air ring 1
19 Oil ring 1
20 Piston Pin Clip 1
21 Piston Pin 1
22 Piston Pin Clip 1
23 Bolt 4
24 Spring Washer 4
25 Bearing Cover 1
26 Bearing Cover Gasket 1
27 Bearing 1
28 Oil Drain Plug 1
29 Oil Sight Glass 1
30 Crankcase 1
31 Bearing Washer 1
32 Spring Washer 1
33 Crankshaft 1
34 Woodruff Key 1
35 Bearing 1
36 Bearing Seat Gasket 1
Part Description Qty
37 Bearing Seat 1
38 Spring Washer 8
39 Bolt 8
40 Breather Washer 1
41 Breather Rod 1
42 Ball 1
43 Breather Washer 1
44 Breather 1
45 Pump Pulley 1
46 Pulley Washer 1
47 Spring Washer 1
48 Bolt 1
49 Air Outlet 1
50 Bolt 4
51 Spring Washer 4
52 Bolt 1
53 Cylinder Head 1
54 Air Filter Rear Cover 1
55 Air Filter Element 1
56 Air Filter Front Cover 1
57 Valve Plate 2
58 Valve Seat 1
59 Valve Plate 1
60 Cylinder Gasket 1
61 Bolt 4
62 Cylinder 1
63 Compression Ring 1
64 Air ring 1
65 Oil ring 1
66 Piston Pin Clip 1
67 Piston Pin 1
68 Piston Pin Clip 1
69 Piston 1
70 Cylinder Gasket 1
71 Connecting Rod 1
72 Air Filter Element 1
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
