Page 9For technical questions, please call 1-888-866-5797.ITEM 61693
SAFETYSETUPOPERATIONMAINTENANCE
Air Line Setup
1. Connect a regulator valve, an inline shut off valve
and a 1/4″ NPT air hose to the Quick Coupler (55)
(all sold separately). The air hose must be long
enough to reach the work area with enough extra
length to allow free movement while working.
Note: An in-line shutoff ball valve is an important
safety device because it controls the air supply even
if the air hose is ruptured. The shutoff valve should
be a ball valve because it can be closed quickly.
2. Depending on the tool which you will be using
with this compressor, you may need to incorporate
additional components, such as an in-line
oiler, a filter, or a dryer (all sold separately),
as shown on Figure G on page 10 and
Figure H on page 11. Consult your air
tool’s manual for needed accessories.
