NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
PARTS LIST
SKU 93760 For technical questions, please call 1-800-444-3353 PAGE 12
Part # Description Part # Description
1 Screw (M5x20) 47 O-Ring (9.5x1.9)
2 Spring Washer (#5) 48 O-Ring (10.3x1.9)
3 Bushing 49 Trigger Valve Head
4 Exhaust Cover 50 O-Ring (12.8x1.9)
5 Seal 51 Spring
6 Screw (M6x30) 52 O-Ring (5.5x1.5)
7 Spring Washer (#6) 53 Trigger Valve Stem
8 Cylinder Cap 54 O-Ring (24.8x2)
9 Gasket 55 Trigger Valve Guide
10 Washer 56 Spring
11 Valve Seat 57 Trigger Spring
12 Spring 58 Trigger
13 O-Ring (57.5x2.6) 59 Spring Pin (2.5x17)
14 O-Ring (72.4x3.5) 60 Rail
15 Valve 61 Washer (#5)
16 Screw (M6x8) 62 Nut (M4)
17 Cylinder Seal 63 Washer (#5)
18 Collar 64 Coil Spring Assembly
19 O-Ring (54.4x4) 65 Pin
20 Piston Assembly 66 Bushing
21 Cylinder 67 Screw (M4x8)
22 O-Ring (72.4x3.5) 68 Block
23 O-Ring (67x3) 69 Spring Washer (#4)
24 Restrictive Plate 70 Screw (M4x12)
25 O-Ring (97.5x3.5) 71 Feeder Shoe
26 Bumper A 72 Screw (M5x14)
27 Bumper B 73 Magazine
28 Body 74 Screw (M4x16)
29 O-Ring (62.3x1.8) 75 Support
30 Nose 76 Nut (M5)
31 Spring Washer (#8) 77 Lock
32 Screw (M8x25) 78 Torsion
33 Spring 79 Bushing
34 Safety Bracket A 80 Nut (M4)
35 Screw (M5x12) 81 Nut (M6)
36 Bushing 82 Soft Grip Sleeve
37 Safety Bracket B 83 O-Ring (65.4x2.5)
38 Washer 84 End Cap
39 Screw (M5x10) 85 Quick Connector
40 Nose 86 Nails (0.131” Dia. x 3” Long, Wire Collated, Full Head, Qty. 100)
41 Seal 87 Nails (0.113” Dia. x 2-1/2” Long, Paper Collated, Clip Head, Qty. 100)
42 Pin 88 Goggles
43 Safety Guide 89 Tool Oil
44 O-Ring (20.3x2.5) 90 Hex Wrenches (Set of 3)
45 O-Ring (20.3x1.5) 91 Carrying Case
46 Valve Set
To Next Page
