Page 12For technical questions, please call 1-800-444-3353.SKU 95310
Part Description Q’ty
1 Rubber Protector 1
2 Oil Seal 1
3 Housing 1
4 Screw 1
5 Bushing 1
6 Anvil Collet 1
7 O-Ring 1
8 Anvil 2
9 Hammer Pin 1
10 Hammer Dog 1
11 Drive Cam 1
12 Hammer Cage 1
13 Bearing 2
15 Front Plate 1
16 Rotor Blade 6
17 Rotor 1
18 Cylinder 1
19 End Plate 1
20 Gasket 1
21 Rear Cover 1
22 Washer 4
Part Description Q’ty
23 Screw 4
24 Rubber Cover 1
25
Pin 1
26
Pin 1
27
Screw 2
28
Mufer Cover 1
29
Trigger 1
30
Trigger Pin 1
33
Screw 1
34
Set Screw 1
35
Spring 1
36
O-Ring 1
37
Regulator 1
38
Valve Seat 1
39
Outer Cover 1
40
Ball 1
41
Spring 1
42
Inlet With Screen 1
43
Valve Screen 1
44
Reverse Valve 1
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
